Ultimate vacuum: 33
Speed: 1450 rpm
Power: 15
Maximum shaft power: 10.8
2BE1 151-0 2BE1 type Liquid Ring Vacuum Pump
Product Features:
The 2BE1 series water ring vacuum pump features a single-stage, single-acting structure, offering advantages such as simplicity, easy maintenance, reliable operation, and high energy efficiency. Compared to the SK, 2SK, and SZ series water ring vacuum pumps currently used in China, it offers significant advantages such as high vacuum levels, low power consumption, and reliable operation, making it an ideal alternative.
All bearings and seals are imported from genuine brands, ensuring stable and reliable operation. The impeller can be made of ductile iron, stainless steel, or alloy steel, ensuring a long product life. The pump body is constructed of steel plate, offering high-quality machining and structural strength.
| Model | r/min | Maximum shaft power kw | Motor power kw | With motor 380V | Ultimate vacuum degree mbar | Maximum gas volume | Pump weight kg | |
| m3/nm | m3/min | |||||||
| 2BE1 151-0 | 1450 | 10.8 | 15 | Y160L-4 | 33 | 405 | 6.8 | 469 |
| 2BE1 152-0 | 1450 | 12.5 | 15 | Y160L-4 | 33 | 465 | 7.8 | 481 |
| 2BE1 153-0 | 1450 | 16.3 | 18.5 | Y180M-4 | 33 | 600 | 10.0 | 533 |
| 2BE1 202-0 | 970 | 17 | 22 | Y200L2-6 | 33 | 760 | 12.7 | 875 |
| 2BE1 203-0 | 970 | 27 | 37 | Y250M-6 | 33 | 1120 | 18.7 | 1065 |
| 2BE1 252-0 | 740 | 38 | 45 | Y280M-8 | 33 | 1700 | 28.3 | 1693 |
| 2BE1 253-0 | 740 | 54 | 75 | Y315M-8 | 33 | 2450 | 40.8 | 2215 |
| 2BE1 303-0 | 740 | 98 | 110 | Y315L-8 | 33 | 4000 | 66.7 | 3200 |
| 2BE1 305-1 | 740 | 102 | 132 | Y355M1-8 | 33 | 4650 | 77.5 | 3800 |
| 2BE1 353-0 | 590 | 121 | 160 | Y355L2-10 | 33 | 5300 | 88.3 | 4750 |
| 2BE1 355-1 | 590 | 130 | 160 | Y355L2-10 | 33 | 6200 | 103.0 | 5000 |
| 2BE1 403-0 | 330 | 97 | 132 | Y315M-4 | 33 | 5160 | 86.0 | 5860 |
| 2BE1 405/406-1 | 330 | 100 | 132 | Y315M-4 | 160 | 6000 | 100.0 | 5980 |
